Our Advanced Machinery Portfolio
At Grape Enterprises, we invest in state-of-the-art equipment to deliver precision tubesheet drilling solutions.
Grape Enterprises operates a modern 1000 sq. meter workshop equipped with advanced CNC Deep Hole Drilling, VTL, and Radial Drilling machines. Our 20T overhead crane and specialized equipment enable us to handle tube sheets up to 3 meters in diameter with precision within tight tolerances required by major industrial clients.
CORE INFRASTRUCTURE
Our Machinery
CNC Deep Hole Drilling Machine
BTA Gun Drill
Find Out More| Control System | Fanuc oi-MF Series |
|---|---|
| X-Axis Travel | 3 meters |
| Y-Axis Travel | 2.5 meters |
| Tube Sheet OD | 3 meters (3000 mm) |
| Thickness Capacity | 800 mm |
| BTA Sizes | Ø16.12 - Ø32.08mm |
| Weight Capacity | 15 MT |
Vertical Turning Lathe (VTL)
VTL-1 (Double Column)
Find Out More| Chuck Diameter | 2.8 meters |
|---|---|
| Swing Diameter | 3 meters |
| Job Height | 2 meters |
| Weight Capacity | 15 MT |
VTL-2 & VTL-3
| VTL-2 Chuck | 2 meters |
|---|---|
| VTL-2 Swing | 2.2 meters |
| VTL-3 Chuck | 1.5 meters |
| VTL-3 Swing | 2.2 meters |
Radial Drilling Machines
RM Series (RM 65, 62, 61)
Find Out MoreOur robust fleet of HMT Radial Drilling machines ensures versatility for various drilling ranges.
| Model | Arm | Swing | Range |
|---|---|---|---|
| RM 65 (4 Qty) | 2m | 3.6m | Ø6-100mm |
| RM 62 (3 Qty) | 1.2m | 2m | Ø6-75mm |
| RM 61 (1 Qty) | 1m | 1.5m | Ø6-50mm |
Machinery Under Retrofitting
CNC Horizontal Drilling
- X-Axis: 3m, Y-Axis: 2.5m
- Tube Sheet OD: 3m
- Thickness: 250mm
CNC VTL (Double Column)
- Chuck: 2m, Swing: 2.2m
- Job Height: 1.2m
- Weight: 8 MT
Key Instruments
| Name | Range |
|---|---|
| Vernier Caliper | 0-2000 mm |
| Micro Meter | 0-50 mm |
| Inside Micrometer | 100-1200 mm |
| Plug Gauges | Ø19.20 - Ø51.44 |
Note: All instruments are calibrated periodically by NABL certified company.
Workshop Infrastructure
- Total Area: 1000 sq. meters with RCC finished floor
- Crane Capacity: 20T Overhead Crane
- Layout: Three optimized spans (2.5m, 2.5m, 10m)
- Safety: Heavy-Duty Chains for secure handling
- Tooling: Fully equipped with all required tools
- Job Capacity: Handling up to 3m Diameter & 15MT Weight
Capabilities Highlight
- Maximum Tube Sheet Diameter: 3 meters
- Maximum Thickness: 800 mm
- Maximum Job Weight: 15 MT
- Precision Tolerances: As tight as 0.02mm
- Material Versatility: Exotic grades, stainless steel, carbon steel
- Efficient material handling with 20T Overhead crane
